Features:

♦ Integrated infrared thermal imaging, visible light camera, pan-tilt control system to achieve day and night all-round video surveillance.

♦ Using temperature measurement thermal imaging technology, it is not limited by light source, and the imaging is clear.

♦ Day and night vision 2MP starlight level low-illumination color camera, which can realize detailed observation;

♦ Visible light camera and thermal imaging camera are managed and set by the same IE or client end.

♦ Support standard ONVIF protocol, back-end compatible with market standard nvr recording and control;

♦ 3D positioning function, which can realize the function of frame selection and zoom and click to center, reduce the difficulty of operation and improve the usability of the device

♦ Universal variable speed PTZ realizes all-round monitoring without blind angle, and achieves high-precision positioning.

♦ The first independent defogging and defrosting module in China which truly solves the problem of lens fogging in the camera compartment caused by temperature differences in the outdoor environment.

♦ The PTZ is equipped with an original voltage stabilization module as standard to filter the instantaneous unstable current of the vehicle and keep the PTZ in a stable state.

♦ The built-in gyroscope and precision transmission scheme realize horizontal and vertical dual-axis image stabilization and fast and accurate positioning.

♦ 360°continuous rotation in the horizontal, Vertical 40°~ -90°,Pan speed 0.1°-40°/s , Tilt speed 0.1°-20°/s.

♦ 256 preset positions, with preset video freeze function.

♦ 6 cruise scans, each can add 32 preset points.

♦ 4 pattern scanning, each path recording time is more than 10 minutes.

♦ The first independent defogging and defrosting module in China which truly solves the problem of lens fogging in the camera compartment caused by temperature differences in the outdoor environment.

♦ The camera compartment uses high-quality heating parts, so that the entire compartment body works together to form an effective anti-fogging and defogging pattern.

♦ The PTZ adopts an integrated structure of upper and lower spindles, so that the PTZ camera bin and infrared bin will not be bumped and misaligned

♦ The PTZ is equipped with an original voltage stabilization module as standard to filter the instantaneous unstable current of the vehicle and keep the PTZ in a stable state.

♦ Support lase rangefinder distance 2km.

Applications of long range thermal PTZ camera
Seaport and airport monitoring.

Marine surveillance.

Water system monitoring.

Storage monitoring.

base security monitoring.

Oilfield & oil depot security.

Fire source prevention & monitoring.

Ecological and environmental monitoring.

Border and coastal defense.

Urban security and anti-UAV applications.

Highways and railways monitoring.

Technical data
