Full HD 1080P Vehicle / Robot Mounted CCTV Security Mobile PTZ Camera

Features

• Acceptable to a variety signals of PTZ ,IP/SDI/AHD/TVI/CVI/Analog.
• Network PTZ supported network and analog dual-outputs, dual control, via RS485 and RJ45 network port.
• With infrared LED range up to 60 meters. It could catch image promptly at night.
• Built-in Defrosting and Defogging devices,which ensures the normal use in temperature difference environment.
• Supporting coordinates and angles to accept instructions.
• PTZ has a built-in Voltage Regulator Module ,protection device for stability and durability.

Description

• High strength alloy aluminum crust, shock resistance, corrosion protection in all weather conditions.
• PTZ support real-time HIKVISION, SONY, Samsung, Hitachi, and other brands HD camera chipset.
• PTZ has super seismic characteristics, this system is especially good for Vehicle monitoring or prison monitoring.
• PTZ has a built-in decoder, integrate multiple protocols.
• 360°Continuously rotation.
• Vehicle power voltage input range: DC10.5V~DC18V.

Application areas:

Applicable to the field of Police, highways, urban management , Law enforcement vehicles, fire fighting truck,Highways,secondary planet communication directorial vehicle, Train and other special vehicle monitoring, Top Mounting, it can be used to obtain evidence, emergency rescue, scene investigation,Construction work, accident treatment, rescue and emergency illumination such as in the bad lighting conditions environment.

Complete system of vehicle / robot mounted PTZ camera

	Vehicle /robot mounted PTZ Camera • Real time video viewing both on local and remote online platform. Anti shock design, perfect for car roof mounted. • IP66 waterproof. • IR Light 3*2W . Night vision up to 60m. • Applied to dynamic forensics system. • 2.0mp 20X optical zoom ptz camera
Vehicle Screen with Joystick ♦ Integration of 8" monitor and 4-dimensional keyboard makes it small volume, light weight and superior appearance. ♦ Used for controlling PTZ camera. ♦ 8" LCD resolution:1280*760. ♦ RS485 control output signals, convenient for controlling device near and in distance. ♦ Input signal is 1 channel VGA HD signal and 1 channel BNC analog signal. ♦ Baud rate:1200 bps~9600 bps; Protocol:Pelco_P,Pelco_D. ♦ Supply voltage:AC/DC 9V~12V; Power:25W
	Vehicle 4 channel NVR • Video Input: aviation connector,digital component signal access.NVR and PTZ camera connect by special aviation cable, support 1 channel 1080P IP PTZ camera input and 4 channel AHD input or analog input. • Video Output:1 channel CVBS output, 1 channel VGA output,(1 channel aviation plug). • Hard disk drive: support 1 2.5" HDD/SSD with SATA interface. The max. storage is 2T. Support 1 SD card at the same time, the max. storage is 128G. • Network port: RJ45 port / 3G/4G port • GPS Port: Built in GPS for vechile position. • Power Supply: DC 8~36V.
Vehicle blacket ● Stable and quick-mount bracket designed for vehicle mobile monitoring equipment installation. ● High strength aluminum alloy material, impact resistance, corrosion resistant, light weight, high strength and strong oxidation resistance. ● Horizontal installation, no need to damage the car roof. ● Independent suspension shock absorption design, shockproof. ● Bracket payload: 200kg ● Length :90cm

Technical data

Shenzhen Okaf Technology Co., Ltd was established in 2005. It is a high-tech enterprise specializing in researching & developing, producing and selling CCTV surveillance products. It is one of the most professional CCTV surveillance system developer & manufacturer in China nowadays.

Our main products apply to public security departments such as: vehicle PTZ Camera, 4G deployment dome camera, vehicle mobile lifter, vehicle mobile lighting devices, dynamic forensics system, highway patrol and rescue system, fire emergency rescue system, urban management law enforcement system, mobile commanding system, operation commanding system etc.

We pay much attention on developing and researching and input a lot of money in new products. The superior performance and low price of Okaf has gained many distributors’ favorable comments, thus the original markets consolidate increasingly, new markets develop constantly. The product quality has had good reputation in domestic and abroad.
